The Nv233 Offers Two Extra Feet of Space Than the Nv213, Seating For Two More Passengers, and a Bold, Performance-Driven Profile. Powered by the PCM ZZ5 5.3L With 400 Lb-Ft of Torque With a 2 :1 Gear Reduction — All Backed by a 1000-Hour warranty — and Equipped With the Standard DropZone Auto Tower by Roswell, This 23-Foot Centurion Is Built for Serious Water Sports.
With up to 5000 pounds of ballast capacity and SeaFlo’s Fast Mover pumps on each ballast area moving an impressive 13.5 gallons per minute, you will not waste preciouses ride time. Opt for Centurion’s exclusive RAMFILL² ballast system and fill more than half of that weight in under 90 seconds. The Nv233 is a surf powerhouse — built on our Opti-V Hull with available QuickSurf Pro, plug-n-play rear ballast, and a Silent Stinger Wake Plate with Lenco Smart Ram for an epic, smooth, adjustable ride that is also inside-voice quiet. And with the Nv Series’ Gator-stepped space between the DropZone Auto Tower and the Centurion Cropped Windshield by PCMW, it’s easier than ever to stay in close contact with your rider — perfect for coaching or celebrating that new trick. On top of all that, the optional Surf Ready package that includes the Champ Sound System by Wet Sounds, Roswell MAG swivels, a big bimini for all-day shade, and a fitted cover by Great Lakes make sure you’re set up for epic sessions from day one. The Nv233 leaves nothing out — except your next day on the water.
Length
23 Ft 3 In
Draft
36 In
Weight
5425 Lbs
Weight on Trailer
6600 Lbs
Fuel Capacity
70 Gal
Beam
102 In
Standard Torque
409 Ft/Lbs
Max Torque
465 Ft/Lbs
Seating Capacity
14 People
Total Available
5000 Lbs
Bow Ballast Tank
450 Lbs
Optional Bow Ballast*
350 Lbs
Optional Rear Ballast*
1500 Lbs
Optional Transform Ballast*
–
Sub-Floor Pumped Ballast
2700 Lbs
*Optional Plug and Play Ballast
Overall Length
28 Ft 7 In
Trailer Width
8 Ft 6 In
Height w/ Tower
10 Ft 6 In
Height w/ Tower Down
8 Ft 5 In
Height w/out Tower
7 Ft 6 In
Height, 18” Wheel Package (Add)
–
Length w/out Platform, Tongue Swing
25 Ft 10 In
Length w/out Platform
27 Ft 3 In
*PPT = Predator Power Tower / DZT = DropZone Tower
Five Year Base Limited Warranty
Lifetime Limited Warranty on Deck, Hull & Stringer System
Five Year Engine/Power Train and Trailer Warranty (660-1000 hours)
Three Year Audio & Electronics Warranty
Two Year Gel Coat Warranty
Gel Coat Scheme: Core | Hull Main Front: Brilliant Purple Metal Flake | Hull Base: White Frost | Swim Step: Brilliant Purple Metal Flake | Tower: Dropzone Auto Tower | Tower Color: White | Tower Accent: Brilliant Purple Metal Flake | Upholstery Scheme: All Hex | Upholstery Main: Charcoal | Upholstery Base: Whisper Gray | Upholstery Accent: White Frost | Upholstery Welt: Charcoal | Stitching Accent: White | Dash Accent: Charcoal | Interior Side Panel: Brilliant Purple Metal Flake | Gator Step Flooring Scheme: 2-Color Centurion Cut | 1st Color Top: GS Shark Fin | 2nd Color Bottom: GS Silver Cloud | Stereo: Centurion Hero System by Wet Sounds | Speaker Color: White
Fineline Industries LLC reserves the right to change model specifications, standard and optional equipment, color schemes and pricing at any time without notice or incurring obligations. It is the Dealer’s responsibility to adhere to all State and Local regulations and laws governing minimum requirements needed on each boat, such as trailer brakes, kill switches and other safety equipment.
Features and Options
Thoughtful Features And Desirable Options
We offer a long list of desirable options to enable you to customize your boat to match your needs. Here are a few popular choices.
QuickSurf Pro with Lenco Smart Rams (Optional)
Ski Pylon (Standard)
50th Anniversary Billet Badge (Standard)
Tandem Axle Boatmate Trailer (Standard)
Centurion Decal (Standard)
Cool Touch Upholstery (Optional)
Silent Stinger Wake Plate (Optional)
Flip-Up Interior Stadium Seating (Optional)
Centurion Surge Thruster System (Optional)
Roswell MAG Swivel Board Racks (Optional)
Fast Mover Ballast System (Standard)
Centurion Cropped Windshield (Standard)
Hero System by Wet Sounds (Optional)
RAMFILL2 “The Baller” (Optional)
Knob Ops (Standard)
High Definition Rear Camera (Optional)
Cobra Racing Driver’s Seat w/ Swivel and Flip-Up Bolster (Standard)
Walkthrough Trash Shoot (Standard)-Features-Options-Gallery_9
Hinged Shocked Lounge Seating with Rhino-Lined Storage (Standard)
Transom Remote (Optional)
12 Warriors Duo Sound System (Optional)
Centurion EVO Touch Vision Dash System (Standard)
DropZone Auto Tower (Standard)
Take a Walkthrough
(coming soon)
With its 20 degrees of deadrise at the transom, the Opti-V hull displaces more water, before any extra weight is added, while preserving a great rough water ride.
At each corner of the transom a flat triangle extends towards bow creating lift along the rear half of the boat for a level running attitude, front to back as well as side to side. Due to this balanced design, the Opti-V Hull enhances fuel economy and provides a much quieter ride than most boats delivering this type of power. With hook built into the rear edge of delta pad, the seated driver can see over the bow while pulling a rider without compromising the waves or wakes thanks to a level running attitude. The hull also deflects rollers, at the bow and transom, so big water can’t spoil your fun. It’s clear the Opti-V Hull delivers the best waves, wakes and ride - in all conditions.
Our ballast is distributed evenly throughout the boat, displacing weight along the entire running surface to create a longer wave and balanced running attitude, front to back, with virtually no bow rise to distract the driver. We believe this creates a superior experience for drivers, passengers and riders.
The Nv233 comes with as many as six precisely placed ballast locations that, when combined, create 5000-pounds of displacement. And for 2026, that weight moves faster than ever thanks to Centurion’s standard Fast Mover Ballast System by SeaFlow, which cuts fill times by more than 68%. This 23’ 3” performance machine can hold up to 14 people while pushing out the kind of wave that makes you want to go all day long.
We love the fact that Centurion offers more than 50% better fuel efficiency than any other water sports boat out there. After all, better fuel efficiency means more time on the water and a less expensive ride for you. But how can we be so much more fuel efficient? It’s the design.
Centurion’s Opti-V may be a modified deep-v hull designed to maximize displacement, but the running surface has a lot of lift built into it. This eliminates drag and creates balance for less resistance, meaning the engine doesn’t have to work as hard to push a Centurion through the water whether it is weighted to ride or set-up for a cruise.
We have a nickname for the available RAMFILL² ballast system. We call it the “Baller.” It’s a nearly maintenance free system that offers 2600 pounds – plus of ballast capacity that fills in 90 seconds.
With its four stainless steel two-inch valves (two in two out), anything plastic is eliminated. The large sub-floor tanks extend from the helm to the transom on each side of the lounge. This just adds to the well-distributed ballast placement and helps create longer waves with consistent push from the face to the curl crash. Baller, indeed.
Up. Down. Dialed In. Standard on every Centurion, the DropZone Auto Tower (DZAT) is built for strength, style, and seamless function.
With dual Linak electric actuators and floating mounts, it folds down in 10 seconds and rises in 14—quiet, smooth, and free of vibration. Just press and hold the rocker switch, and let it do the work. The patented CAM latch and compact design keep it secure and sleek, while side tow points help riders of all styles get up and going. Built-in center hangers hold ropes, towels, and vests, and courtesy lighting keeps everything visible, even after sunset. It’s strength you can feel, performance you can trust, and function you’ll never want to go without.
